Feature
- Digital and analog supported
- Safe communication
- Convenient operation
- Solid outer casing
Specifications
| Channels | 16 |
|---|---|
| Frequency Range | 136–174MHz/ 350 –400MHz/ 400–470MHz |
| Modulation | 11K0F3E @12.5KHz 16K0F3E @25KHz |
| 4FSK Digital Modulation | 12.5KHz Data Only: 7K60FXD; 12.5 KHz Data & Voice: 7K60FXW |
| Modulation Limiting | ±2.5KHz @12.5KHz; ±5KHz @25KHz |
| Channel Spacing | Analog: 6.25/ 12.5KHz; Digital: 12.5/ 25KHz |
| Frequency Stability | ±2ppm |
| Input Voltage | 7.4V (Rated) |
| Battery | 1500/ 2500mAh (Li-ion) |
| Operating Temperature Range | -20°C to +55°C |
| Storage Temperature Range | -40°C to 85°C |
| Antenna Impedance | 50ohm |
| Water Resistance | IP54 Standard |
| Electro-Static Discharge | IEC 61000-4-2 (Level 4); ±8kV (Contact); ±15kV (Air) |
| Output Power | 5W (High)/ 2W (Low) |
| Conducted/ Radiated Emission | -36dBm 1GHz |
| Adjacent Channel Power | -60dB @12.5KHz; -70dB @25KHz |
| Audio Response | +1 to -3dB |
| Audio Distortion | ≤3% |
| Selectivity | Analog: -121dBm; Digital: 120dBm (BER ≤3 %) |
| Audio Output Power | 1W (Rated) |
| Distortion | ≤3% (Rated) |
| Conducted Spurious Emission | Less than -57dBm |
| Dimensions | 60(W) x 120(H) x 35(D) mm (Projections not included) |
| Weight | Approx. 225g |
